Alloy Steel Bevel Gear
Alloy Steel Bevel Gears for Heavy Loads and Long Life, Heat Treated to Suit the Duty.
| Gear Type | Spiral bevel, shaft angle 90° unless the drawing says otherwise |
|---|---|
| Made To | Customer drawing, CAD model or worn sample |
| Supplied As | Matched gear and pinion set, or single gear on request |
| Inspection Record | Dimensions, hardness and tooth contact on request |
| Steels | EN19, EN24, EN353, 20MnCr5, SAE 8620 |
| Teeth | Straight or spiral |
Strength for Heavy-Duty Drives
Alloy steel bevel gears are for drives where carbon steel would wear out too quickly or break under shock. The alloying elements let the steel harden deeper and stay tough, so the gear lasts longer under load.
Steels and Treatment
We cut bevel gears from EN19 and EN24 for hardened and tempered duty, and from case-hardening steels such as 20MnCr5 and SAE 8620 where a hard surface is wanted over a tough core. For larger gears we use forged blanks.
Straight and Spiral
Both straight and spiral bevel teeth can be made in alloy steel. If your drive runs fast or must be quiet, choose alloy steel spiral bevel gears. For slow drives, straight teeth in alloy steel are a simple and strong choice.
Quality Checks
Each gear is checked for dimensions and hardness, and a set is checked for tooth contact against its mate. A material certificate can be supplied.
Frequently Asked Questions
Which alloy steel is used for bevel gears?
EN19 and EN24 for hardened and tempered duty, and case-hardening grades such as 20MnCr5, EN353 and SAE 8620 for a hard surface on a tough core.
Can the gears be supplied hardened?
Yes. We supply them hardened and tempered, or carburised and hardened, depending on the duty.
Do you supply material certificates?
Yes, on request.
